Lincoln® Type K231 Submerged Arc Welding Gun

Item No.
Part No.
Description
Item No.
Part No.
Description
1
M8249
Cone Body Assembly
8
-
Flux Hose Insulator
2
S10157
Nozzle Body Assembly
9
T10642-2
Flux Hose
3
S10493-1
Nozzle Insulator
10
T10570
Special Socket Head Screw
4
S10147
Retaining Nut
11
CF000052
Hexagon Head Screw
5
KP2085-1
Flux Cone
12
CF000027
Hexagon Nut
6
-
Contact Tip 5/64, 3/32, 1/8, 5/32, 3/16"
13
-
Washer
7
T10574
Locking Ferrule
14
T9078-1
Thumb Screw

Miller® Type OBT-600 Submerged Arc Welding Gun

Item No.
Part No.
Description
Item No.
Part No.
Description
1
192 693
Cone Body Assembly
7 + 8
192 694
Flux Hose with Insulator
2
192 692
Nozzle Body Assembly
9
-
Hexagon Head Screw
3
192 697
Retaining Nut
10
-
Hexagon Nut
4
192 696
Flux Cone
11
-
Washer
5
-
Contact Tip 5/64, 3/32, 1/8, 5/32, 3/16"
12
-
Thumb Screw
6
192 695
Locking Ferrule




Miller® Type OBT-1200 Submerged Arc Welding Gun

Item No.
Part No.
Description
Item No.
Part No.
Description
1
049 740
Wire Inlet Guide 5/32 - 1/4 in
6

192 141
Contact Tip 1/16 in
081 925
Wire Inlet Guide 1/16 - 1/8 in
199 026
Contact Tip 5/64 in
199 945
Wire Inlet Guide 5/32 - 1/4 in
192 142
Contact Tip 3/32 in
199 946
Wire Inlet Guide 1/16 - 1/8 in
200 771
Contact Tip 7/64 in
2
192 132
Inlet Guide Adaptor
192 143
Contact Tip 1/8 in
3
192 131
Torch Body Assembly
192 144
Contact Tip 5/32 in
4
192 139
Wire Liner 1/16 - 1/8 in
192 136
Contact Tip 3/16 in
192 687
Wire Liner 5/32 - 3/16 in
200 756
Contact Tip 7/32 in
200 754
Wire Liner 7/32 in
7
192 135
Tip Nut
5
192 133
Tip Extender
8
192 758
Securing Clamp

9
192 137
Flux Nozzle Assembly

10
192 138
Flux Replaceable Nozzle

SAF / ESAB Submerged Arc Welding Consumable

Item No.
Part No.
Description
1
-
Contact Tip, SAF Subarc, All Sizes
2
-
Contact Tip, SAF Twin Wire (MIG / Submerged Arc Welding)
3
-
Contact Tip, ESAB A2 Submerged Arc Welding, All Sizes
4
-
Contact Jaw, ESAB A6 Submerged Arc Welding, 3mm / 6mm
5
-
Submerged Arc Welding Roller for ESAB A6
